New challenges for High Voltage transmission
In able to fully integrate renewable energies and to stop to use fossil energy and nuclear power, there is a need to evolve the current electric grid in a new one called the supergrid. This new grid will be based on a mix of High Voltage AlternativeCurent (HVAC) and High voltage Direct Current (HVDC) junctions highly meshed with Gas Insulation Substation (GIS) as nodes. While HVAC GIS technologies are well mastered, HVDC ones are still at the beginning. One weakness of the equipment being dielectric insulators, industries may have to conceive new dielectric formulations or improved ones. This paper presents a list of properties and values to target for future dielectrics formulation. At the end, it highlights as well, the importance of health and environnement and how their consideration have to be at the same level of attention than the final properties of the dielectrics.
Power electronic traction transformers in 25 kV / 50 Hz systems: Optimisation of DC/DC Isolated Converters with 3.3 kV SiC MOSFETs
In AC electric trains, power electronic traction transformers (PETT) are multilevel single phase AC/DC converters connected to the AC medium voltage overhead line. For indirect topologies, DC/DC isolated converters are key elements of PETTs. This paper shows a method to design such DC/DC converters, and several variants are considered. Finally, the comparison results, in the case of a 25 kV / 50 Hz power supply and 3.3 kV SiC MOSFETs, show that the variant with a resonant AC link, with only one controlled bridge and a switching frequency lower than the resonant frequency, offers the best efficiency at rated power for a given volume.
A New Energy Management Control of Modular Multilevel Converters for Coping with Voltage Stress on Sub-Modules
This paper investigates the impact of the operating condition on the SM voltage ripples. In particular, it is revealed that under the classical control scheme where the Modular Multilevel Converter internal energy varies naturally with the DC grid voltage, the traditional sizing approach based on the analytical expression of instantaneous SM voltage may fail to respect the SM voltage constraint. To tackle this problem, this paper presents a solution by incorporating the advantages of the explicit energy management and the developed analytical expressions of the SM voltage ripple, which achieves a better utilization of the converter asset.
Packaging Solution for SiC Power Modules with a Fail-to-Short Capability
Fail-to-short packages, which can still carry current after the failure of their semiconductor devices, are required for HVDC applications. However, all existing solutions are dedicated to silicon components. Here, a fail-to-short package is proposed for SiC devices. Its manufacturing process is described. 4 modules are built and submitted to intense short circuit currents (up to 2000 A). It is found that they offer a stable short-circuit failure mode, providing that the modules are mechanically clamped to prevent separation during the surge current test.
Fault behaviour of bipolar overhead line based HVDC grids
This paper provides a fault analysis of bipolar overhead line based HVDC grids using HB-MMC converters. The impacts of fault type and fault resistance are shown and the physical behaviour of the transient fault return current is explained.
FMEA of a non-selective fault-clearing strategy for HVDC grids
The Failure Mode Effect Analysis (FMEA) is a technique used to investigate failures in a process or component and to identify the resultant effects of these failures on system operations. In this paper it is explained how the FMEA can be used to define and assess the impact of the failure modes (FM) of a protection strategy for High Voltage Direct Current (HVDC) grids.
Study of the impact of DC-DC converters on the protection strategy of HVDC grids
This paper studies the role of DC-DC converters in the protection of HVDC grids acting as firewalls to stop the propagation of faults. The effects of blocking the converter or actively controlling its operation during faults are presented.The results demonstrate the capabilities of DC-DC converters beyond DC voltage transformation.
Power system stability enhancement via VSC-HVDC control using remote signals: Application on the Nordic 44-bus test system
In this paper the benefits of embedded VSC-HVDC links with supplementary controls for small-signal stability enhancement purposes using remote signals are studied and applied on the Nordic Grid.
25 kV-50 Hz railway power supply system emulation for Power-Hardware-in-the-Loop testings
This paper presents a methodology to consider the impedance of a grid in power hardware in the loop (PHIL) experiments to validate power converter control in presence of harmonics or resonances in the network impedance. As the phenomena to emulate are in a large frequency range, the skin effect in conductors has to be taken into account. A procedure is developed to model the network.
Dielectric properties of ceramic substrates and current developments for medium voltage applications
Why are ceramic materials (when compared to organic materials) necessary for the purpose of electric isolation in power modules, especially for medium voltage applications...
