This work focuses on the transmission grid level and investigates the control of VSCs interfacing renewable sources in hybrid power systems where PE and SG coexist.
A contribution to the development of high-scale HVDC systems, particularly regarding insulation coordination for Voltage Source Converter (VSC) based technologies.
A contribution to the development of high-scale HVDC systems, particularly regarding insulation coordination for Voltage Source Converter (VSC) based technologies.
In the framework of the research activities of the High Voltage Substation Equipment program of SuperGrid, it has been proposed to introduce such species by means of an evaporative liquid spray. The interaction between injected droplets and the mixture of hot gases successively flowing into the chamber and vented outside the chamber during the mechanical separation of the electric contacts should allow spray evaporation and transport of the modified gas mixture towards the arc region.
The work of this thesis focuses on the experimental development of a passive and biphasic cooling system to cool down power electronics. Some of those modules are mean voltage power converters developed by Supergrid Institute. Some constraints have been imposed upstream to this project. While some limitations are of the technological nature, other constraints are related mainly to the environmental and biological aspects. The first part of this thesis was to find a suitable cooling system that could be adapted to the project specifications. After some research, we decided to build a loop thermosiphon filled with NOVEC 649.
Energy Transition for a more sustainable world is now the priority in societies. Towards this objective, especially in Europe, the offshore wind energy development has been relatively rapid. For Offshore Wind Power Plants (OWPP) farther from the shore (50 km and beyond) Voltage Source Converter (VSC) based High Voltage DC (HVDC) Transmission has become the prominent solution. Replacement of the offshore VSC station by multiple Diode Rectifier Units (DRUs) led to a cheaper, more compact and robust solution. This thesis focusses on various technological and scientific problems involved in the control system of the Offshore Wind power Plant with Diode Rectifier (DR) based HVDC transmission. These challenges are first reviewed in detail along with the state of the art. Then, based on the system dynamics, a grid forming control scheme is proposed by using the P-V and Q-f droop relationships, with a solution for the synchronization of the wind generators. Moreover, some of the selected control solutions in the literature for this topology are reviewed, compared and assessed by using time domain simulations of a study case. Following this, the different solutions for black start of the offshore AC system are analyzed from the available literature and they are compared using the relevant qualitative criteria. The various faults in the offshore system are then analyzed and the above designed grid forming control scheme is extended with Fault Ride through (FRT) capability, for offshore AC grid faults. Finally, a brief analysis is done on the challenges for the integration of this OWPP topology into a Multi Terminal DC (MTDC) network.
In order to include large-scale renewable sources into the electrical system and to transport high amounts of energy through long distances, the actual AC grid must be upgraded. HVDC transmission grids appear as a promising solution to upgrade the system and answer correctly the future needs and requirements. The development of such grids can be done following two different approaches. For one side, a DC system designed totally from zero following a standardization of HVDC technology, and for the other side, an incremental evolution using the existing HVDC lines. The second approach seems more reasonable due to the reutilization of infrastructure, the inconvenient is that the technology used on each existing line is different. Thus, their interconnection will require DC¬DC converters as interface elements. These structures allow the interconnection of different HVDC schemes and offer more functionalities than only DC voltage adaptation like power flow control and protection.
High Voltage Direct Current (HVDC) grids are considered a promising solution for problems faced by nowadays power system such as: lines congestion, integration of large amounts of renewable power and enhancement of AC system stability. Among the challenges in the deployment of a HVDC meshed grid, the protection of these grids is regarded as one of the most critical. The protection of HVDC grid is challenging not only because the swift transients and fault currents without zero-crossing, but also due to the impact a DC faults can have on the AC system. Several propositions for HVDC grids protection strategies can be found in literature...
This study aims to examine possible impact of these harmonics in presence of microcavities. Depending on their size and on the electrical field, partial discharges (PD) can occur in these microcavities. Two types of cables have been aged: a medium voltage AC (MVAC) cable with millimetric cavities induced artificially and a model cable with an HVDC XLPE grade.
The work presented in this manuscript has been motivated by the necessity to develop more efficient electrical insulating materials compared to commercially available ones. An epoxy-anhydride matrix filled with micron sized alumina, often used to produce GIS solid insulators, has been used as a reference for this study.
